Wholesale Diaphragm dc12v Small Urea 20 Liters Oil Adblue Chemical Pump
Whaleflo Diaphram Adblue pumps and accessories
Suitable for use other liquids from the urea manufacturing process. They are diaphragm pumps with a by-pass Which is designed to dispense products called Ad Blue, AUS32 or water, and also widely used in chemical equipment, agriculture (lawn and garden), carpet cleaning, floor/ground cleaning, and water treatment equipment.
Suitable for IBC transmission systems, permanent magnet pumps work continuously.
Specification
Model Number: HV-25B
Body Materials: Aluminum
Voltage: DC 12V
Current: 6.0A
Pressure off: 60~80PSI
Frequency: 50/60Hz
Flow(Liters/Min):17- 25L(4.5-6.6GPM)
Power: Electric
Pressure Switch: Build in
Speed: 2700rpm
Liquid of Transfer: AdBlue, AUS 32, Water etc.
IP55 Protection, CE
Features&Highlights
Whaleflo Diaphragm Adblue Pump material: aluminum alloy, durable, corrosion resistant, high quality
Permanent magnets and continuous load: maintain a good motor to maintain a stable temperature of the 2m wire plug of the pump body
Whaleflo Self-priming water pump: can be located above the water tank and dry in a short time (up to 20 minutes) without damage
Easy to operate: on/off switch, built-in pressure switch for automatic start or stop when the faucet is opened and closed
Application: Suitable for applications where liquids are transferred from one location to another, such as AdBlue, AUS32 or water etc, spraying, recycling, irrigation and distribution
Note:They must not pump gasoline, chemicals, high viscosity liquids, solvents, etc.
Item Code
Volt
Flow Rate(L/min)
Pressure (PSI)
Amps(A)
Speed(rpm)
HV-25A
12V DC
17-25
60-80
10.0
2700
HV-25B
24V DC
17-25
60-80
6.0
2700
HV-25S
115V AC
17-25
60-80
1.5
2700
HV-25M
230V AC
17-25
60-80
1.0
2700
